Angular Network Aware Preload Strategy

2019-12-22 · 1 min

Lazy loading routes

As an app grows, with modules grouping feature components, a common approach is to lazy load each module from the main routing configuration. Angular recommends this from the start, because it's a simple, scalable way to load a module's dependencies only when its route is activated. You've probably seen or written this in app-routing.module.ts:

import { NgModule } from '@angular/core';
import { RouterModule, Routes } from '@angular/router';

const routes: Routes = [
            {
                path: 'index',
                loadChildren: 'src/app/modules/home/home.module#HomeModule'
            },
            {
                path: 'shop',
                loadChildren: 'src/app/modules/shop/shop.module#ShopModule'
            }
];

Or, from Angular 8:

import { NgModule } from '@angular/core';
import { RouterModule, Routes } from '@angular/router';

const routes: Routes = [
            {
                path: 'index',
                loadChildren: () => import('src/app/modules/home/home.module').then(m => m.HomeModule)
            },
            {
                path: 'users',
                loadChildren: () => import('src/app/modules/user/user.module').then(m => m.UserModule)
            }
];

The second form uses dynamic import(), which is widely supported.

Either way, each module loads when someone first visits its route.

Preloading everything

The standard way to preload these modules is the PreloadAllModules strategy. It loads every module in the routes array in the background, so there's no delay between a user clicking a route such as /users and its module downloading.

imports: [
  ... // omitted for brevity
  RouterModule.forRoot(routes,
    { preloadingStrategy: PreloadAllModules })
]

Network-aware preloading

PreloadAllModules is great on a fast connection, but not everyone is on one. A user on a slow mobile connection, or with data saver switched on, will have every module downloaded in the background whether they ever visit those routes or not, competing with the bandwidth the current page needs.

Angular lets us decide this ourselves by providing a custom PreloadingStrategy. It has a single method, preload, which the router calls for each route that uses loadChildren. Returning load() preloads the module, returning of(null) skips it.

To decide, we can use the Network Information API. navigator.connection exposes effectiveType ('slow-2g', '2g', '3g' or '4g') and saveData, which is true when the user has asked their browser to use less data.

import { Injectable } from '@angular/core';
import { PreloadingStrategy, Route } from '@angular/router';
import { Observable, of } from 'rxjs';

@Injectable({ providedIn: 'root' })
export class NetworkAwarePreloadStrategy implements PreloadingStrategy {
  preload(route: Route, load: () => Observable<any>): Observable<any> {
    return this.hasGoodConnection() ? load() : of(null);
  }

  private hasGoodConnection(): boolean {
    const connection = (navigator as any).connection;

    if (!connection) {
      return true; // API not supported, behave like PreloadAllModules
    }

    if (connection.saveData) {
      return false;
    }

    return !['slow-2g', '2g'].includes(connection.effectiveType);
  }
}

Then swap it in for PreloadAllModules:

imports: [
  ... // omitted for brevity
  RouterModule.forRoot(routes,
    { preloadingStrategy: NetworkAwarePreloadStrategy })
]

Skipped modules aren't lost. They load on demand when the user visits the route, exactly as in the lazy loading examples above.

Browser support

At the time of writing, navigator.connection is only available in Chromium-based browsers. That's why the strategy falls back to preloading everything when the API is missing, so those users get the same behaviour as PreloadAllModules. Treat this as a progressive enhancement rather than something to depend on.
